Olympus M.Zuiko Digital ED 100-400mm f/5-6.3 IS M.ZUIKO
Overview
The Olympus M.Zuiko Digital ED 100-400mm f/5-6.3 IS is a high-performance super-telephoto zoom lens designed for the Micro Four Thirds system. Offering a 35mm equivalent focal length of 200-800mm, it delivers exceptional reach in a compact, weather-sealed package—ideal for wildlife, sports, and aviation photography.
Key Features
Exceptional Reach & Optical Quality
-
Impressive Zoom Range – Covers a 200-800mm equivalent, bringing distant subjects like birds, wildlife, and aircraft remarkably close without disturbing their natural behaviour.
-
High-Grade Optics – The complex optical construction features 21 elements in 15 groups, including four ED (Extra-low Dispersion), two Super HR, and two HR elements, ensuring sharp, high-contrast images with minimal colour bleeding.
-
ZERO Coating – Zuiko Extra-low Reflection Optical coating effectively reduces ghosting and flare, delivering clear image quality even in challenging backlit conditions.
Versatile & Portable Design
-
Compact & Lightweight – It is remarkably portable for a lens of this focal range, making it practical for handheld shooting during extended outdoor sessions.
-
Telemacro Capability – With a minimum focus distance of 1.3m across the entire zoom range and a maximum magnification, it excels at capturing detailed close-ups of small, skittish subjects like insects.
-
Robust Weather-Sealing – Featuring IPX1-rated splash-proof and dust-resistant construction, it offers reliable performance in demanding outdoor conditions.
Performance & Handling
-
In-Lens Image Stabilisation – Built-in optical IS with up to 3.5 stops of compensation provides stable handheld shooting at extreme focal lengths.
-
Fast, Quiet Autofocus – The high-speed imager AF (MSC) system delivers snappy, silent focusing, ideal for both stills and video.
-
Extensive Expandability – Fully compatible with the MC-14 1.4x and MC-20 2x teleconverters, extending the reach to an incredible 1600mm equivalent.
-
Focus Limiter & Controls – A focus limiter switch offers three AF operating ranges for faster, more precise focusing, especially in the super-telephoto range.
Conclusion
The Olympus M.Zuiko Digital ED 100-400mm f/5-6.3 IS is a powerful, portable, and value-packed super-telephoto zoom that is a firm favourite among wildlife and outdoor photographers. Its exceptional reach, robust build, and close-focus capability make it a versatile tool for capturing distant subjects and intricate details. its outstanding sharpness, comprehensive feature set, and compatibility with teleconverters make it a standout choice for the Micro Four Thirds system.
Olympus M.Zuiko Digital ED 100-400mm f/5-6.3 ... Specs
| Focal Length |
100 to 400mm (35mm Equivalent: 200 to 800mm)
|
| Aperture |
Maximum: f/5 to 6.3
Minimum: f/22
|
| Lens Mount |
Micro Four Thirds
|
| Lens Format Coverage |
Micro Four Thirds
|
| Angle of View |
12° to 3.1°
|
| Minimum Focus Distance |
4.27' / 1.3 m
|
| Magnification |
1:1.75 Macro Reproduction Ratio
0.57x Magnification
|
| Optical Design |
21 Elements in 15 Groups
|
| Aperture/Iris Blades |
9, Rounded
|
| Focus Type |
Autofocus
|
| Image Stabilization |
Yes
|
| Tripod Mounting |
Removable and Rotating Collar
|
| Filter Size |
72 mm (Front)
|
| Dimensions |
ø: 3.4 x L: 8.1" / ø: 86.4 x L: 205.7 mm
|
| Weight |
2.46 lb / 1120 g
|
